Approx. 22.3 mm x 14.9 mm CMOS

Approx. 24.1 megapixels

Approx. 24.7 megapixels

3:2

Built-in/Fixed

Manual cleaning and Dust Delete Data acquisition

RGB Primary Colour

DIGIC 4+

EF/EF-S

Equivalent to 1.6x the focal length of the lens

Optical Image Stabilizer provided on compatible lenses

Via optical viewfinder:
TTL secondary image-forming phase-difference detection system with AF-dedicated sensor
Via Live View on LCD screen:
Contrast detection AF

Via optical viewfinder:
9 AF points (f/5.6 cross type at centre)

Via optical viewfinder:
Centre AF point: EV 0 -18 (at room temperature & ISO100)
Other AF points: EV 1 -18 (at room temperature & ISO100)
Via Live View LCD screen:
EV 1 -18 (at room temperature & ISO100)

Via optical viewfinder:
AI Focus (Switches between One-Shot AF and AI SERVO AF automatically)
One Shot AF
AI Servo
Manual
Via Live View LCD screen:
One Shot AF (Contrast detect AF)
Quick Mode (via phase detection AF sensor)
Manual

Via optical viewfinder:
Automatic selection from up to 9 points
Manual selection
Via Live View on LCD screen:
FlexiZone - Freely position 1 AF point via manual selection
Live Mode - Automatic selection with face detection

Indicated by superimposed display in the viewfinder and on the LCD monitor

Yes

Locked when shutter button is pressed half way in One Shot AF mode. Customisation available via AE Lock Button

Intermittent firing of built-in flash or emitted by optional dedicated Speedlite (effective up to 4.0 m)

Selected on lens

Via optical viewfinder:
Evaluative via 63 zone dual-layer metering sensor (linked to all AF points)
Partial (centre, approx. 10% of viewfinder)
Centre-weighted average available
Via Live View on LCD screen:
Evaluative metering (315 zones)

Via optical viewfinder:
EV 1-20 (at room temperature, ISO 100, evaluative metering)
Via Live View on LCD screen:
EV 0-20 (at room temperature, ISO 100, evaluative metering)

Auto: In 1-shot AF mode with evaluative metering exposure is locked when focus is achieved.
Manual: By AE lock button in creative zone modes.

+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).

3 shots +/- 2 EV, 1/2 or 1/3-stop increments

AUTO(100-6400), 100-6400 in 1-stop increments
ISO can be expanded to H: 128001
During Movie shooting: Auto (100-6400), 100-6400 (Whole stop increments)

Electronically-controlled focal-plane shutter, with electronic first curtain

30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)

Auto white balance with the imaging sensor

AWB (Ambience priority, White priority), Daylight, Shade, Cloudy, Tungsten, White Fluorescent light, Flash, Custom (Approx. 2000 K - 10000 K).
White balance compensation:
Blue/Amber +/-9
Magenta/ Green +/-9.

Yes, 1 setting can be registered

+/-3 levels in single level increments
3 bracketed images per shutter release.
Selectable Blue/Amber bias or Magenta/Green bias.

Pentamirror

Approx. 95%

Approx. 0.80x2

Approx. 21mm (from eyepiece lens center)

-2.5 to +0.5 m-1 (dioptre)

Fixed

Quick-return half mirror

Yes, assigned to SET button

On strap

7.5 cm (3.0") TFT LCD, approx. 920 K dots

Approx. 100%

Approx. 170°

Adjustable to one of seven levels

Quick Control Screen
Camera settings

9.2

up to 17mm focal length (35mm equivalent: 28mm)

Approx. 2 seconds

Auto, Manual Flash On/off

Yes - with red eye reduction lamp

X-contact not equipped, Max. flash sync speed: 1/200 sec. with compa
